| DVI 101 |
|
| Video |
|---|
| Maximum data rate | 4.95 Gbps (1.65 Gbps per color) |
| Maximum pixel clock | 165 MHz |
| Resolution range | Up to 1920x1200 or 1080p @ 60 Hz |
| Formats | RGB and YCbCr digital video |
| Standards | DVI 1.0, HDMI 1.2 |
|
| Video input |
|---|
| Number/signal type | 1 single link DVI-D (or HDMI*) |
| Connectors | 1 female DVI-I |
| Input cable length | Up to 200' (61 m) at 1920x1200 or 1080p @ 60 Hz
Up to 250' (76 m) at 1024x768, 720p, or 1080i @ 60 Hz
Longer distances are possible with lower rates and/or high quality cable. |
| NOTE | The transmission distance varies greatly depending on the signal resolution and on the type of cable, graphic card, and display used in the system. |
|
| NOTE | *Appropriate DVI-D to HDMI cables or adapters are required for HDMI signal input/output. |
|
| Equalization | Automatic for up to -40 dB of cable loss |
|
| Video output |
|---|
| Number/signal type | 1 single link DVI-D (or HDMI*) |
| Connectors | 1 female DVI-I |
| Output cable length | Up to 15' (5 m) |
|
| General |
|---|
| Power | Supplied by an external power supply or by the 5 V signal from a DVI source (pin 14) or an HDMI source (pin 18) |
| Power supply | External
Input: 100-240 VAC, 50/60 Hz
Output: 12 VDC, 0.5 A, 6 watts |
| Power input requirements | 12 VDC, 0.2 A from an external power supply or
5 VDC, 0.05 A from a DVI source or an HDMI source |
| Ambient temperature/humidity | Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing |
| Cooling | Convection, no vents |
| Mounting | |
| Rack mount | Yes, with optional rack mounting kit |
| Furniture mount | Yes, with optional rack mounting kit |
| Enclosure type | Metal |
| Enclosure dimensions | 1.0" H x 2.2" W x 3.0" D (one-eighth rack wide)
(2.5 cm H x 5.6 cm W x 7.6 cm D) |
| Product weight | 0.4 lbs (0.2 kg) |
| Regulatory compliance | CE, C-tick, c-UL, UL, FCC Class A, ICES, VCCI |
| Product warranty | 3 years parts and labor |
| Everlast power supply warranty | 7 years parts and labor |
| NOTE | All nominal levels are at ±10%. |
|
| NOTE | Specifications are subject to change without notice. |
|
| (4350-D8) |
