| DA 6A |
|
| Audio |
|---|
| Gain | Unity when internal jumpers are set to match output wiring. See the table below for other conditions. |
| |  |
| Frequency response | 20 Hz to 20 kHz, ±0.05 dB (with voltage reference @ 1 kHz) |
| THD + Noise | 0.03% @ 1 kHz at nominal level |
| S/N | >90 dB, unbalanced/balanced, at maximum output (unweighted) |
| Stereo channel separation | >80 dB @ 1 kHz, >60 dB @ 20 kHz |
| CMRR | >75 dB @ 20 Hz to 20 kHz |
| Output cable driving distance | Up to 1000 feet with STP 22 cable |
|
| Audio input |
|---|
| Number/signal type | 1 stereo, balanced/unbalanced |
| Connector | (1) 3.5 mm captive screw connector, 5 pole |
| Impedance | >18k ohms unbalanced, >24k ohms balanced, DC coupled |
| Nominal level | Compatible with +4 dBu (1.23 Vrms), 0 dBu (0.775 Vrms), -10 dBV (316 mVrms), -20 dBV (100 mVrms) |
| Maximum level | +24 dBu, (balanced) at 1%THD+N |
| NOTE | 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu |
|
|
| Audio output |
|---|
| Number/signal type | 6 stereo, balanced/unbalanced |
| Connectors | (6) 3.5 mm captive screw connectors, 5 pole |
| Impedance | 50 ohms unbalanced, 100 ohms balanced |
| Maximum level (Hi-Z) | >+24 dBu, balanced at 1%THD+N |
| Maximum level (600 ohm) | >+15 dBm, balanced at 1%THD+N |
|
| General |
|---|
| Power | 100 VAC to 240 VAC, 50-60 Hz, 8 watts, internal |
| Ambient temperature/humidity | Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing |
| Mounting | |
| Rack mount | Yes, with optional 1U deep rack shelf |
| Furniture mount | Yes, with optional under-desk mounting kit or through-desk mounting kit |
| Enclosure type | Metal |
| Enclosure dimensions | 1.7" H x 8.7" W x 6.0" D (1U high, half rack wide)
(4.3 cm H x 22.1 cm W x 15.2 cm D)
(Depth excludes connectors.) |
| Product weight | 2 lbs (0.9 kg) |
| Shipping weight | 4 lbs (2 kg) |
| Vibration | ISTA 1A in carton (International Safe Transit Association) |
| Regulatory compliance | |
| Safety | CE, c-UL, UL |
| EMI/EMC | CE, C-tick, FCC Class A, VCCI, ICES |
| MTBF | 30,000 hours |
| Product warranty | 3 years parts and labor |
| Everlast power supply warranty | 7 years parts and labor |
| NOTE | All nominal levels are at ±10%. |
|
| NOTE | Specifications are subject to change without notice. |
|
| (5551-D8) |
